| 参数 | 标称效率 KW | 标称功率 A | 恒扭矩调频条件 Hz | 恒最大功率变频器时间范围 Hz | 堵转惯量 额定功率电动机扭矩 Tst/TN | 堵转电流大小 电机额定功率瞬时电流 Ist/TN | 最好扭矩 载荷系数传动比 Tmax/TN | 最少惯量 固定扭矩 Tmin/TN |
| YVF2-7114 | 0.25 | 0.8 | 5-50 | 50-100 | 2 | 9 | 2.8 | 1.7 |
| YVF2-7124 | 0.37 | 1.1 | 1.7 | |||||
| YVF2-80M1-4 | 0.55 | 1.5 | 1.7 | |||||
| YVF2-80M2-4 | 0.75 | 2 | 1.6 | |||||
| YVF2-90S-4 | 1.1 | 2.8 | ||||||
| YVF2-90L-4 | 1.5 | 3.7 | ||||||
| YVF2-100L1-4 | 2.2 | 5.1 | 1.5 | |||||
| YVF2-100L2-4 | 3.0 | 6.8 | ||||||
| YVF2-112M-4 | 4.0 | 11.4 | ||||||
| YVF2-132S4 | 5.5 | 15.3 | 1.4 | |||||
| YVF2-132M-4 | 7.5 | 22.1 | ||||||
| YVF2-1160M-4 | 11 | 30.1 | ||||||
| YVF2-160L-4 | 15 | 35.4 |
